PACIFIC-S2 Enterprise SSD
High-Endurance Performance Solution Engineered for Core Databases and High-Frequency Trading
Product Introduction: PACIFIC-S2 is a high-performance, mixed-use enterprise SSD from Telin Semicon, forged from entirely independent
intellectual property.
Featuring a self-developed 8-core controller and a high-performance 16-channel architecture, integrated with advanced 3D eTLC NAND, it is
purposefully engineered to conquer the most rigorous challenges of core databases and complex mixed workloads.
The PACIFIC-S2 not only delivers a massive throughput of up to 7.1GB/s and a formidable 500K IOPS steady-state random write performance, but
also guarantees ultimate stability. With a superior 3 DWPD (Drive Writes Per Day) endurance rating and hardware-level Power Loss Protection
(PLP), it ensures long-term reliability and extreme consistency even in the most intensive high-frequency write/erase environments.
The PACIFIC-S2 not only delivers a massive throughput of up to 7.1GB/s and a formidable 500K IOPS steady-state random write performance, but
also guarantees ultimate stability. With a superior 3 DWPD (Drive Writes Per Day) endurance rating and hardware-level Power Loss Protection
(PLP), it ensures long-term reliability and extreme consistency even in the most intensive high-frequency write/erase environments.
Core Value Proposition
High-Performance Write Cycles
Delivers a formidable 500K IOPS steady-state random write performance, engineered to manage transaction surges and complex data processing with ease.
PCIe 4.0 x4 NVMe 1.4a
Next-generation high-speed interface to ensure high-bandwidth throughput, effectively shattering data transfer bottlenecks.
Mission-Critical Stability
Increased OP to ensure consistent, non-degrading performance even under long-term, full-load operation in mission-critical environments.
Ultra-Low Write Latency
An optimized write-path architecture significantly slashes wait times for database commits and log journaling, radically solving latency issues.
3 DWPD Endurance
Built for write-intensive environments, providing a superior lifespan of 3 DWPD to effortlessly handle frequent data updates and high-intensity workloads.
Universal Compatibility
Supports both x86 and ARM server platforms.
| Model | X2-01T6U2 | X2-03T2U2 | X2-06T4U2 |
|---|---|---|---|
| Capacity | 1.6TB | 3.2TB | 6.4TB |
| 128k Sequential Read | 6.4 GB/s | 7.1 GB/s | 7.1 GB/s |
| 128k Sequential Write | 2.7 GB/s | 4.8 GB/s | 5.8 GB/s |
| 4k Random Read (IOPS) | 759K | 1.3M | 1.7M |
| 4k Random Write (IOPS) | 200K | 500K | 500K |
| 4k Read Latency (AVG) | 85 μs | 85 μs | 85 μs |
| 4k Write Latency (AVG) | 8 μs | 8 μs | 8 μs |
| MTBF | 2 Million hours | 2 Million hours | 2 Million hours |
| UBER | 1 sector per 10^17 bits read | 1 sector per 10^17 bits read | 1 sector per 10^17 bits read |
| DWPD | 3 | 3 | 3 |
| Typical Power | 18W | 18W | 18W |
| Form Factor | U.2 15mm | U.2 15mm | U.2 15mm |
| Interface | PCIe 4.0 x4, NVMe 1.4a | PCIe 4.0 x4, NVMe 1.4a | PCIe 4.0 x4, NVMe 1.4a |
| NAND Flash | 3D eTLC NAND Flash | 3D eTLC NAND Flash | 3D eTLC NAND Flash |
| Platform Compatibility | Supports x86 architecture, ARM architecture | Supports x86 architecture, ARM architecture | Supports x86 architecture, ARM architecture |
Ideal Applications
Purpose-Built for Write-Intensive and High-Pressure Hybrid Workloads】
AI Model Training
Ensures maximum reliability for frequent checkpointing and continuous parameter updates throughout the most demanding AI model training cycles.
OLTP Databases
Optimized for core SQL/NoSQL databases and real-time order processing, providing the high-endurance required for frequent and intensive record updates.
High-Frequency Trading (HFT)
The premier choice for financial trading systems, delivering the ultra-low write jitter and extreme consistency essential for millisecond-level transaction execution.
Edge Computing
Acts as a high-performance gateway for edge intelligence, efficiently processing and storing high-frequency sensor data streams in real-time.
Virtualization (VDI）
Expertly handles "write storms" within Virtual Desktop Infrastructures (VDI) during simultaneous virtual machine (VM) boot-ups and high-concurrency operations.
End-to-End Data Path Protection
Maintains data integrity from the host to the NAND flash.
LDPC Error Correction + RAID
Advanced error checking and correction for enhanced data reliability.
Power Loss Protection (PLP)
Onboard capacitors ensure data in-flight is written to NAND during power failure.
5-Year Limited Warranty
Backed by our commitment to enterprise-grade quality and support.
Technical Support: newweblink@china.com
